Sensor cooling
-
Sony CCD 2/3” monochrome sensor
-
CCD Array 1360 x 1024
-
22 fps at full resolution
-
USB 3.0 digital Interface
-
1”, C-mount optical interface
| Sensor type | Sony ICX-825 Scientific Interline CCD monochrome |
| CCD Array | 1360 x 1024 |
| Pixel Size |
6.45 μm x 6.45 μm |
| Active Area |
8.8 mm x 6.6 mm (11 mm diagonal) |
| Peak Quantum Efficiency |
75% at 600 nm |
| Full Well Capacity |
>11,000e- single pixel |
| Digital Output |
14 bit at 50 MHz |
| Digitization Rate |
USB3 – 50 MHz high frame rate, 650 kHz low noise mode USB2 – 17.5 MHz high frame rate, 650 kHz low noise mode |
| Read Noise (typical) |
50 MHz – < 7 e- RMS 650 kHz – < 5 e- RMS |
| Frame Rate |
22 fps at full resolution 31 fps binned 2x2 |
| Exposure Time Range |
25 μs – 5 sec |
| Supported Binning Modes |
1x1, 2x2, 4x4, 6x6, 8x8, 12x12, 16x16 |
| Dark Current Rate (typical) |
0.0005 e/p/s at -20C regulated |
| Sensor Cooling |
0° C stabilized at 22° C ambient Thermoelectric cooling with forced air |
| Operating Systems/Platforms | Windows 7 (64 bit), Windows 8 (64 bit), and Windows 10 (64 bit) |
| Digital Interface |
USB 3.0 (USB 2 compatible at reduced max fps) |
| Optical Interface |
1”, C-mount optical format |
| Mounting Hole Thread Size |
1/4” - 20 thread, 4 sides |
| Camera Dimensions |
98.4 mm x 76 mm x 76 mm (length x width x height) |
| Weight |
0.72 kg, 1.55 lb |
| Power Requirement |
7V DC, 5A |
| Supplied Accessories | Power Cords (GB, US, EU, CN, JP), Power Supply, USB 3.0 Cable, Trigger Cables, Sensor Plug, Grounding Cable |
